reliable, fuel efficient performance
FUEL OPERATION, HIGH OUTPUT GENERATION
The GX100's Precision Camshaft design offers precise valve timing and optimal valve overlap for better fuel efficiency.
It draws on decades of Honda engineering with its OHV design, delivering increased efficiency and optimal power transfer for where you need it.
And the GX100 incorporates a high compression ratio for better fuel efficiency.
The GX100 engine is frequently used by customers in commercial lawn and garden equipment.
The GX100 engine is suitable for a wide range of heavy-duty applications, construction equipment, portable generators, pumps and other industrial applications.
A ball bearing-supported crankshaft and precision engineered components result in greater stability and lower vibration making it easier to use over prolonged periods of time.
The use of lightweight, noise-reducing materials and a forged steel crankshaft & rigid crankcase results in an exceptionally quiet engine that incorporates a large capacity, multi-chamber exhaust system.
And with a sophisticated air intake system, oil alert, large fuel tank, easily accessible spark plug and cast iron cylinder sleeve, the GX100 will work as hard with minimal fuss.
YOUR ENGINE IN DETAIL
|Type||4-stroke, overhead valve, single-cylinder, horizontal shaft|
|Bore & Stroke||56 x 40mm|
|Net Power||2.1kW (2.8HP) at 3,600rpm|
|Continuous Rated Power||1.7kW (2.3HP) at 3,600rpm|
|Max Net Torque||5.7 Nm at 2,500 pm|
|Ignition System||Transistorised magneto ignition|
|Starting System||Recoil Starter|
|PTO Shaft Rotation||Counter-clockwise (from P.T.O. side)|
|Fuel Consumption at Rated Power||0.88 L/h at 3,600rpm|
|Recommended Oil||10W/30 API SG|
|Fuel Tank Capacity||0.77L|
|Dimensions||295 x 304 x 402 mm|
the honda advantage
3 year warranty
Honda's leading range of power equipment comes with leading warranty periods. Our range of GX engines carrying up to a 3 year warranty*.
With regular servicing by a Honda authorised dealer, using only Honda Genuine Parts and Accessories, your Honda product will work hard around your home for many years.
Find more details on Honda's warranties and the warranty schedule on our warranty page.
Ready to take the next step towards your Honda engine? With our nationwide network of dealers, from the far north to the deep south and everywhere in between. You can purchase online, or enquire now for more information on Honda Engines.
